Description
HPE MB2000FCZGH 2TB 7200RPM 3.5inch Large Form Factor Dual Port SAS-6Gbps Hot-Swap Midline Hard Drive for Generation1 to Generation7 Servers (New Bulk Pack with 90 Days Warranty
HPE Server Midline Hard Drives deliver the highest capacity, performance and reliability to your datacenter applications. Midline hard drives allow you to store more data without sacrificing performance or reliability; they are ideal to store all your bulk storage requirements. HPE Server Midline Hard Drives are available in both 3.5-inch Large Form Factor (LFF and 2.5-inch Small Form Factor (SFF and ship with a standard one-year warranty. All HPE hard drives pass a rigorous qualification process, which certify that every drive is proven to perform in your HPE ProLiant Server environments. Before final certification, all HPE Server Midline Hard Drives are optimized for compatibility and functionality, including support of SMART and HPE Systems Insight Manager.
Designed and Engineered to Provide High Capacity and Reliable Secure Storage
HPE Server Midline Hard Drives are ideal for the growing volume of digital content, bulk data storage, cloud and web infrastructure environments. Broad portfolio of optimized solutions provide up to 12 TB of storage, and growing in a single device. Rotational Vibration Sensors deliver enhanced rotational vibration tolerance that provides enterprise class reliability in midline drives. Available in 2.5-inch Small Form Factor (SFF and 3.5-inch Large Form Factor (LFF in a wide variety of capacity points.
Serial Attached SCSI (SAS is the logical evolution of SCSI including its long-established software advantage and the serial physical connection interface. With enterprise storage requirements escalating and becoming more complex factors such as larger capacity greater density security scalability and accessibility are more critical than ever. Enterprise data centers must be online all the time fulfill requests from numerous users simultaneously allow for constant growth and expansion and be maintained while in operation. Serial Attached SCSI (SAS meets all these demands while providing the highest performance.
The HPE MB2000FCZGH Midline Hard Drive has a 3.5 inch form factor and a 6 Gbps external data transfer rate. It has a spindle speed of up to 7200 RPM and a 2 TB capacity. This Large Form Factor Dual Port hard drive uses a SAS-6Gbps (serial attached SCSI interface and has 90 Days Warranty.
Specifications
Brand: HPE
MPN: MB2000FCZGH
Option Part Number: 507616-B21
Spare Part Number: 508010-001
Model Number: MB2000FCZGH
Assembly Number: 698695-001
General
Device Type: Hard Drive - Hot-Swap
HDD Capacity: 2 TB
Form Factor: 3.5 inch LFF
Interface: SAS-6Gbps
Bytes per Sector: 512
Buffer: 16 MB
Drive Technology (Fill: Air
Carrier Type: Standard Carrier
Workload: Midline
Features: Dual Port
Bundled with: HPE Standard Carrier
Performance
Seek Time: 8.5 ms (average / 16.2 ms (max
Spindle Speed: 7200 RPM
External Data Transfer Rate: 600 MBps
Track-to-Track Seek Time: 0.5 ms
Expansion & Connectivity
Interfaces: 1 x SAS 6 Gb/s
Compatible Bay: 3.5" LFF
Dimensions & Weight
Width: 4.30 inch
Depth: 7.40 inch
Height: 1.00 inch
Environmental Parameters
Min Operating Temperature: 50 °F
Max Operating Temperature: 95 °F
Compatibility Information
Designed For
HPE ProLiant DL Series: DL1000 DL120 (Gen6 Gen7 DL160 (Gen6 Gen7 DL160se (Gen6 Gen7 DL165 (Gen6 Gen7 DL170e (Gen6 Gen7DL170h (Gen6 Gen7 DL180 (Gen6 Gen7 DL320 (Gen6 Gen7 DL360 (Gen4p Gen5 Gen6 Gen7 DL365 (Gen1 Gen5 Gen6 Gen7DL370 (Gen6 Gen7 DL380 (Gen4 Gen5 Gen6 Gen7 DL385 (Gen1 Gen2 Gen3 Gen4 Gen5/Gen5p Gen6 Gen7DL580 (Gen3 Gen4 Gen5 Gen6 Gen7 DL585 (Gen2 Gen3 Gen4 Gen6 Gen7 DL785 (Gen6
HPE ProLiant ML Series: ML 110 (Gen7 ML350 (Gen5 Gen6 Gen7 ML370 (Gen5 Gen6 Gen7 ML570 (Gen3 Gen4 Gen5
HPE Storage Systems: D2700 MSA 1040 MSA70 P2000 (Gen3 X1500 (Gen2 X16000 (Gen2 X1800 (Gen2 X3400 (Gen2
HPE StoragEeasy: X3800 (Gen2 2000i (Gen2 2000sa (Gen2
Contact us if you have any question about this product to verify this model’s compatibility with your current server or storage array.
Warranty Information
90 Days Warranty
