| Image Sensor & Optics |
1/2.8 type CMOS, approx. 2.0 million effective pixels, progressive scan.
20x optical zoom (4.7 mm (W – 94 mm (T, 16x digital zoom, auto focus.
F-number: F1.6 (W – F3.5 (T.
16:9 FOV: Horizontal 62.4° (W – 3.3° (T; Vertical 36.3° (W – 1.9° (T.
4:3 FOV: Horizontal 47.9° (W – 2.5° (T; Vertical 36.3° (W – 1.9° (T.
Day/Night switch with IR cut filter: Auto / Day Mode / Night Mode. |
| Low-Light Performance |
Day Mode (color: 0.02 lux (F1.6, shutter speed 1/30 sec., 50 IRE.
Night Mode (monochrome: 0.003 lux (F1.6, shutter speed 1/30 sec., 50 IRE.
Shooting distance from front of lens: Day Mode 0.3 m (W / 1.0 m (T to infinity; Night Mode 1.0 m (W / 1.5 m (T to infinity.
With dome enabled: Day Mode 2.0 m (W, T to infinity; Night Mode 1.0 m (W / 2.2 m (T to infinity. |
| Exposure & Image Control |
Shutter speed: 1/1, 1/2, 1/4, 1/8, 1/13, 1/15, 1/25, 1/30, 1/50, 1/60, 1/100, 1/120, 1/250, 1/360, 1/500, 1/720, 1/1000, 1/1400, 1/2000, 1/3000, 1/4000, 1/6000, 1/8000, 1/10000, 1/16000 sec.
Exposure modes: Auto, Auto (Flickerless, Auto (Shutter-priority AE, Auto (Aperture-priority AE, Manual.
White balance: Auto / Manual.
Metering modes: Center-weighted, Average, Spot, Specify Area.
Exposure compensation: 13 levels.
WDR, Smart Shade Control, Haze Compensation, AGC Limit, Motion-adaptive NR available.
Image stabilizer available (except at maximum frame rate of 60 fps / 50 fps. |
| PTZ Performance |
Pan angle range: 340° (±170°.
Tilt angle range: 100° (ceiling-mounted position: -90° to +10° when camera horizontal angle is 0°.
Pan speed: max. 150°/sec.; Tilt speed: max. 150°/sec.
Presets: up to 64 preset positions (+ Home Position.
Preset tour routes: up to 5. |
| Video Streaming |
Compression: JPEG, H.264, H.265.
Resolutions (JPEG/H.264/H.265: 1920 x 1080, 1280 x 720, 960 x 540, 640 x 360, 480 x 270, 320 x 180, 1280 x 960, 640 x 480, 320 x 240.
Frame rate (60 Hz: 1, 5, 7.5, 10, 15, 30, 60 fps.
Frame rate (50 Hz: 1, 2.5, 5, 6.25, 10, 12.5, 25, 50 fps.
Video quality: 10 levels (JPEG, H.264, H.265.
Simultaneous clients: max. 30 Clients + 1 Admin Client (H.264 max. 10 clients, H.265 max. 10 clients.
Bit rate control: CBR, VBR, MBR (Maximum Bit Rate.
ADSR (Area-specific Data Size Reduction available. |
| Network & Protocols |
Network terminal: RJ45, 100Base-TX (auto.
Protocols: IPv4, IPv6, TCP/IP, UDP, HTTP, SNMPv1/v2c/v3 (MIB2, DHCP, DNS, AutoIP, mDNS, ARP, ICMP, POP3, NTP, SMTP, RTP/RTCP, RTSP, SSL/TLS, ONVIF, WV-HTTP (Canon proprietary.
ONVIF profiles: Profile S, Profile G, Profile T. |
| Security Features |
User levels: Administrator, Authorized user, Guest user (control varies by level.
Access control: User authentication (user name and password, host access restrictions (IPv4, IPv6.
IEEE802.1X: EAP-TLS, EAP-TTLS, EAP-PEAP.
Encrypted communications: SSL/TLS. |
| Audio |
Compression: G.711 μ-law (64 kbps, AAC (16/48 kHz, 16/32/64/96/128 kbps.
Communication: Full-duplex (two-way / half-duplex, via RTP and Canon Sound Transfer Protocol.
Audio input terminal: 3.5 mm mono mini-jack (LINE IN / MIC IN.
Audio output terminal: 3.5 mm mono mini-jack (LINE OUT.
Audio file playback available. |
| Storage & Edge Recording |
Memory card: SD, SDHC, SDXC supported (Class 10 recommended.
SD card backup recording supported. |
| Interfaces & I/O |
Network: LAN x 1 (RJ45, 100Base-TX, auto.
Audio: 3.5 mm mono mini-jack for LINE IN/MIC IN and LINE OUT.
External device I/O: 2 x inputs, 2 x outputs. |
| Intelligent Functions & Events |
Intelligent functions: Moving Object Detection, Abandoned Object Detection, Removed Object Detection, Camera Tampering Detection, Passing Detection, Intrusion Detection, Volume Detection, Face Detection.
Event triggers: External device input, Intelligent Function, Timer, Day/Night Mode switching.
Linked events: up to 2; conditions: OR, AND (with or without sequence.
Image upload: FTP/FTPS/HTTP/HTTPS/SMTP/SMTPS (e-mail.
Event notification: HTTP/HTTPS/SMTP/SMTPS (e-mail.
Log notification: SMTP/SMTPS (e-mail.
Panorama, view restriction, privacy mask, enhanced digital zoom, on-screen display available. |
| Applications & Language Support |
Camera software: Camera Management Tool, Recorded Video Utility.
Web interfaces: Page, Camera Viewer, Mobile Camera Viewer in multiple languages including German, English, Spanish, French, Italian, Russian, Thai, Korean, Simplified Chinese, Japanese.
Recorded Video Utility and Camera Management Tool additionally support Polish and Turkish. |
| Environmental & Power |
Operating temperature (DC, PoE: -10 °C to +50 °C (+14 °F to +122 °F.
Operating humidity: 5% to 85% RH (non-condensing.
Storage temperature: -30 °C to +60 C (-22 °F to +140 F.
Storage humidity: 5% to 90% RH (non-condensing.
Power supply: PoE (IEEE802.3at Type 1 compliant, 12 V DC, optional AC adapter PA-V18 (100–240 V AC.
Power consumption: PoE max. approx. 9.1 W; DC max. approx. 7.9 W; AC adapter max. approx. 9.2–9.7 W. |
| Mechanical & Dimensions |
Dimensions (Φ x H: Φ132 x 155 mm (Φ5.20 x 6.10 in., camera only (excluding ceiling plate.
Weight: approx. 1100 g (2.43 lb..
Pan/Tilt mechanism and dome design optimized for indoor ceiling mounting with wide movement range. |
| Certifications & Standards |
EMC and emissions: EN 55032 Class A, FCC Part 15 Subpart B Class A, ICES-003 Class A, VCCI Class A, RCM AS/NZS EN55032 Class A, CNS13438 Class A, EN 55035, IEC EN 63000:2018, CNS15663.
Safety: IEC/EN 62368-1 3rd ed., UL 62368-1 3rd ed. |
